This fiber separator machine is used to separate fine fibers from rubber powder in the waste tire recycling line, particularly for nylon tires. It serves to greatly enhance the purity of rubber powder, thus improving the quality and usability of recycled rubber. Its capacity is 800-1000kg/h, and it’s optional for the whole rubber tire recycling.
In addition to being used in the rubber industry, this equipment is also widely used in the chemical industry for grading granular powder materials and separating fine powders. This rubber fiber separator is multi-purpose and highly efficient. If interested, please contact us for more details!
Technical parameters of rubber fiber separator machine
From the table below, the model is TFS-1000, which should be equipped when finer rubber particles are required. You can also know its capacity, dimension, weight, etc. for your reference when choosing this equipment.
| Model | TFS-1000 |
| Motor power | 5.5 KW |
| Speed of motor | 760r/min |
| Capacity | 800-1000kg/h |
| Size(L*W*H) | 1500*1500*3400mm |
| Weight | 1600 kg |
Tire fiber separating machine structure & working principle
Our tire recycling fiber separation equipment is mainly composed of frame, host chamber, air selection system, motor drive device and discharging port.
Its core principle is to separate the lighter nylon fiber from heavier rubber powder through the centrifugal force and airflow formed by high-speed rotation, to achieve the separation effect. Together with multiple air separation and screening, the fiber content can be reduced to less than 5%, which meets the high requirements for purity in the back-end products processing.
Wide range of application areas of fiber separator machine
This kind of fiber removing machine for rubber powder is widely used in:
- Scrap tire recycling processing line
- Rubber powder reuse production
- Recycled rubber manufacturing enterprises
- Chemical powder classification system
Its functionality is not limited to the tire industry, but can also be used as powder sorting equipment in several industrial scenarios.
Why choose Shuliy fiber separator machine?
Shuliy, as a manufacturer of recycling equipment for many years, has the following advantages:
- Machine built to industry-leading standards
- Multi-country export, support voltage customization, and video guidance
- One-stop recycling solutions, providing the whole set of tire recycling equipment(like tire sidewall cutter, block cutter, strips cutter, rubber powder machine, etc.)
- Customized rubber tire recycling solutions, export packaging details, and after-sales service
Contact us for a free quote now!
Get in touch with us and tell us your needs, such as product fineness, budget, and we will provide you with the optimal rubber tyre recycling program according to your needs.
